DE160100 AMD Kria SoM PCIe Development Kit is a feature-rich, high-performance carrier board carefully designed to unlock the full potential of the AMD Kria™ K26 System-on-Module (SoM). While the K26 SoM itself integrates a powerful AMD Zynq™ UltraScale+™ MPSoC, memory, boot, and security module into a compact form factor, the AMD Kria SoM PCIe Development Kit dramatically expands its connectivity and application capabilities.

This carrier board provides an extensive array of industry-standard interfaces, facilitating prototyping and deployment for complex embedded systems. Key interfacing options include versatile high-speed data ports such as 4-port USB 3.0, DisplayPort 1.2a, dual SFP+ cages for flexible optical networking, and comprehensive PCIe connectivity with both x1 PCIe Gen3 Endpoint and x2 PCIe Gen3 Root Complex capabilities. Storage solutions are robust, featuring an M.2 SATA slot, a uSD Card interface, and an 8 kbit EEPROM for non-volatile configuration data.

Networking is well-supported with both 1G PS Ethernet and 1G PL Ethernet ports. For imaging and vision applications, the card incorporates an RPi Camera CSI-2 interface and a generic IAS (Image Sensor) Interface. Development and debugging are streamlined with onboard JTAG, dual PMOD connectors for extendibility, an LPC FMC connector for further expansion, and dual UART to USB converters for easy console access. Industrial connectivity is also a core focus, with integrated CAN bus and dual RS-485 transceivers.

Key Features

• PCIe Gen3 x2 Root Complex
• PCIe Gen3 x1 Endpoint
• 4-Port USB 3.0 Hub
• DisplayPort 1.2a
• 1G PS ethernet (RJ45)
• 1G PL ethernet (RJ45)
• Dual SFP+ Cages
• M.2 SATA connector (M-Key)
• MicroSD card slot
• LPC FMC connector
• Dual PMOD connectors
• Raspberry Pi camera interface (CSI-2)
• Generic IAS (image sensor) interface
• Dual RS-485 transceivers
• CAN bus transceiver
• Dual UART-to-USB bridges
• System health monitor IC
• Hardware watchdog timer
• 8 kbit I²C EEPROM
